Brightness

• 3200 ANSI lumens

• 90% brightness uniformity

Contrast Ratio

• 800:1

Resolution

• 3 x 0.99" p-Si Active Matrix TFT LCD panels

• True XGA 1024 x 768

• 8-bit color resolution offering 16.7 million displayable colors

Dynamic Scaling

• Digital scaling of VGA to SXGA resolutions

• Digital de-interlacing of STV, DTV and HDTV formats with DDT technology

Horizontal Frequency Range

• 15 to 100 kHz

Vertical Frequency Range

• 50 to 100 Hz

Dot Clock

• 140 MHz

Optional Lenses

• Standard lens: 1.6-2.1:1 zoom

• Medium throw 1.2-1.6:1 zoom lens

• Long throw 2.1-3.4:1 zoom lens

Vertical Lens Shift:

• From 10:0 (up) to 1:1 on axis

Inputs

• Input 1: Digital RGB DVI-I or Analog RGB (15pin D-sub); Audio Input (1 x 3.5mm mini stereo)

• Input 2: Composite (RCA), YPbPr, and YUV video (3-RCA connection). S-Video (4 pin mini DIN). Audio Input (2x RCA L/R)

• Control Port Input: (mini DIN 8-pin x 1 USB type B x 1)

Outputs

• Two built-in 2W RMS speakers (per channel) and amplifier

• Monitor out (HD-15)

Source Compatibility

• Compatibility with VGA, SVGA, XGA, SXGA and MAC computer sources

• Accepts composite video, S-Video and component video from VCR, DVD, Laser Disc players and video cameras

• Auto detects PAL, PAL-M, PAL-N, NTSC, NTSC4.43 and SECAM video standards

• Compatible with DTV/HDTV formats 480i, 480p, 575i, 575p, 720p, 1035i and 1080i

• HDTV compatible, 800 TV lines horizontal resolution

• Digital Visual Interface (DVI-I) compatible

• Progressive scan video decoder with 3D digital comb filter for Y/C separation

Enhanced Feature Set

• 3D Digital Noise Reduction

• Power zoom and focus

• Motorized lens shift (up and down)

• Digital keystone correction, +/- 30° vertical, +/- 10° horizontal

• Digital zoom and pan (Min. x1/4, Max. x49)

• Freeze Frame

• Presentation timer

• Picture and audio mute

• Linear fan control system (FCS) for quiet operation

Control/Networking

• Automatic set-up (phase/tracking/positioning)

• USB Type B

• Remote control jack

• RS232-C communications port via 8-pin mini DIN terminal

• IR remote keypad with laser pointer and mouse control

• Front and rear IR receivers

Graphical User Interface

• Easy set-up and intuitive on-screen displays (OSD)

• Direct key functions

• Choice of image aspect ratios (4:3 or wide 16:9)

• Multi-language On Screen Display (OSD) (English/German/French/Spanish/Italian/Portuguese/Dutch/Swedish/Chinese/Korean/Japanese)

Lamp Specification

• 250W UHP lamp

• User replaceable lamp

• 1000 hours typical life

Power Requirements

• Universal power AC 100 - 240V, 50/60Hz

• Power consumption: 350W typical

• Thermal dissipation: 1194 BTU/hr

• Operating temperature: 0 - 35° C (storage -30° to 60°)

• Operating humidity: 20 - 80% (storage 0 - 90%)

• Acoustic noise level: 32dB in economy mode, fan control system (FCS) for whisper-quiet operation

Weight & Size

• 17.1 lbs (7.8 kg) including lens

• 11.9" W x 6.3" H x 16.6" L

• 302mm W x 162mm H x 422mm L

Standard Accessories

• IR/Wired remote keypad with mouse control and laser pointer

• User manual

• Computer cable

• Mouse control cable (PS/2, Serial and MAC)

• Dust cover

• Lens cover

• AC cord x 2 (UL type and European)

Optional Accessories

• Standard lens: 1.6-2.1:1 zoom

• Medium throw 1.2-1.6:1 zoom lens

• Long throw 2.1-3.4:1 zoom lens

• Lamp module

• Ceiling mount

• Transit case

• Optional ChristieNET connectivity for monitoring and control

Anti-theft Security

• Compatible with Kensington style security mechanisms

Regulatory Approval

• Complies with all relevant worldwide

EMC & Safety standards

• This product complies with FCC class B, CE mark and safety requirements IEC950 (EN60950), UL1950/cUL

Warranty

• Product warranty, 2 years parts and labor (excluding lamp)

• Lamp warranty 120 days/500 hrs, whichever comes first

Reliability

• Mean time between failure (MTBF) over 30,000 hrs
