KEY POINTS - Ce labs c5hdp component cat5 balun transformer:
Uses standard CAT5 or CAT6 cable
Can be used with four composite video channels and mono analog audio
Four RCA connectors for component video and digital SPDIF audio
Heavy gauge steel, powder-coated chassis, is corrosion and scratch resistant
SUMMARY - Ce labs c5hdp Component CAT5 Balun Transformer:
Distribute a high definition component video/digital audio source to a
remote location over extended distances using economical CAT5 cable.
DETAILED SPECS - CE LABS C5HDP COMPONENT CAT5 BALUN TRANSFORMER:
Video:
Nominal input level:
1 Volt peak to peak
Gain:
N/A (passive unit)
Input Impedance:
75 ohms, unbalanced
Output Impedance:
100 ohms, balanced
Isolation port to port:
60 dB
Isolation output to input:
bidirectional
Return loss::
>15 dB
Video bandwidth:
>35 MHz
Audio:
1 Audio Channel Available: may be used to transport a SPDIF digital
audio signal or a mono audio signal(mono analog signal wil be
attenuated slightly due to lower impedance of the digital audio channel)
Distance:
The adapter provides a minimum signal loss and may be used for
high definition distribution with cable lengths up to 200 feet with no
monitor adjustment
