MyScreen, My Memory, Blank/My Button, My Text, My Source, blackboard/whiteboard mode, Daytime Mode, Input Source Naming (English), resolution setting, Template, Closed Caption (for NTSC & component 480i only), Audio pass through
Outward
Easy lamp replace from top, Air filter slides towards front side or top
Power on & off
Quick On, Direct On, Auto Off
Security systems
Security bar, PIN-Lock, MyScreen Password, Keypad-Lock, Kensington slot, Transition detector, My Text, Security label
Network
Configure and control projector via web browser, receive alerts via e-mail, projector management via SNMP, Scheduling, My Image, displaying text data transferred via the network, Command Control via network, AMX Device Discovery, PJ Link™, Network Bridge
CONNECTIONS
Digital input
1 x HDMI
Computer Input
2 x 15-pin Mini D-sub
Computer Output
1 x 15-pin D-sub
Video input
1 x RCA for component
2 x Component D-sub (shared with analogue RGB)
1 x RCA for composite
1 x Mini-DIN for S-Video
Audio input
2 x Stereo Mini Jack
1 x pair RCA (L/R)
1 x Microphone Jack (Stereo Mini)
Audio output
1 x pair RCA (L/R)
Control
1 x 9-pin D-Sub for RS-232C Control
USB Type A/Type B
Yes (PC less presentation)/Yes (USB mouse)
Network
1 x RJ-45
POWER
Power Supply
100-120V / 220-240V auto switching
Power Consumption/Standby
310W/<1W
PHYSICAL
Dimensions (W x H x D)
317 x 98 x 288mm (excluding feet and extrusions)
Weight
3.6Kg
Noise level
36dB (Normal Mode)/29dB (Eco Mode)
Air filter
Super Hybrid
MISCELLANEOUS
Indicator lights (lamp, temp, power), Ceiling mount image, Rear projection image, Serial number label on side
ACCESSORIES SUPPLIED
Remote control with batteries, Computer cable, Power cord, Lens cap, Security label, User manual (detail & concise), Application software for LAN display
Remote control
HL02483
OPTIONAL ACCESSORIES
Replacement lamp
DT01021
Lamp Wattage
210W UHB
WARRANTY
Projector warranty
3 Years
Lamp warranty
6 Months**
*The stated lamp life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps should achieve this figure.
**Where a lamp fails within warranty and a replacement lamp is taken, the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated).
