KEY POINTS - Pioneer vsx1021k 7.1 channel 3d ready home theatre a/v receiver:
AirPlay Compatible
Industry's First AV Receiver Designed for iPad
Network-capable for Internet Radio and DLNA support
Compatible with Pioneer-exclusive Apps Including iControlAV2 and Air Jam
7.1 Channel A/V Receiver
120 Watts x 7 @ 8 Ohms
HDMI Terminals (5 In / 1 Out)
SUMMARY - Pioneer vsx1021k 7.1 Channel 3D Ready Home Theatre A/V Receiver:
The Pioneer 7.1-Channel VSX-1021-K AV Receiver is the answer to a home theater enthusiast's prayers. Delivering remarkable performance in an elegant package, it's a receiver designed with advanced technology that performs exquisitely in the moment, while at the same time never taking its eyes off the future. Its state-of-the-art, forward looking features get you closer to exactly what the artist intended in a way that has never been possible. Until now.
DETAILED SPECS - PIONEER VSX-1021-K 7.1 CHANNEL 3D READY HOME THEATRE A/V RECEIVER:
Power
Amplifier Design
Direct Energy
Channels
7.1
Power Output Per Channel(20Hz-20kHz,.08%THD@8ohm)
90
Power Output Per Channel (1kHz@8ohm)
110
Power Output Per Channel (1kHz@6ohm)
130
Handheld and Internet
Made for iPod Certified
Made for iPhone Certified
Made for iPad Certified
Supported Apple Devices
5th gen. Nano and Above / iPhone, 3G, 3GS, 4, iPad
AirPlay
iControlAV2 iPhone Application
iControl AV2 iPad Application
Pioneer Air Jam Application
Yes (AS-BT200 required)
Supplied iPod/iPhone/iPad A/V Cable
USB + Composite Video
Battery Charger
5th gen. Nano and Above / iPhone, 3G, 3GS, 4, iPad
iTunes Movie / TV / Video Playback
YouTube Video Playback
iTunes Album Art
iTunes Cover Art
DLNA 1.5
Android Audio Playback via USB
Internet Radio
Yes
VTuner Internet Radio
Decoders & Formats
Digital Core DSP Engine
Texas Instruments Aureus
THX Certification
No
iPod Digital Audio
192K/24-Bit DACs
Dolby True HD
Dolby Digital Plus
Dolby Pro-Logic Iiz
DTS-HD Master Audio
192kHz / 24-Bit
WAV, LPCM via Ethernet
96kHz / 24-Bit
FLAC via Ethernet
Neural THX Surround
HDMI SACD Transfer
Multi-Channel
Soundfield Calibration
Phase Control
Auto MCACC
Advanced
Manual MCACC
Standing Wave Control
EQ Bands
9-Band
Symmetric EQ
MCACC Memory
6
X-Curve
Distance Adjustment
1/2 inch
Polarity Check
Auto Subwoofer Crossover
Listening Modes
Auto Surround
Stream Direct
Yes (Direct, Pure Direct)
Advanced Surround
15+1 Mode DPS
Wide Surround
Front Stage Surround Advance
Yes (Focus, Wide)
Headphone Surround
Virtual Surround Back
Virtual Height
Audio Features
DSD to PCM Converter
Multi- Channel
PQLS Jitter Reduction
Bit Stream
Auto Level Control
Multi- Channel
Apple Lossless Playback
Dialog Enhancement
Advanced Sound Retriever
Multi- Channel / Auto
Auto Sound Retriever
Sound Retriever AIR
Digital Noise Reduction
Tone Control
2 Channel
Sound Delay (Lip Sync)
Yes (10 Frames)
Speaker A/B
Versatile Speaker Configuration
Bi-Amp
Yes (Front Channel)
Video Processing
3-D Ready
Audio Return Channel
HDMI Standby Through
HDMI 36-bit Deep Color
HDMI x.v. Color
Video Processor
Anchor Bay
Video Converter to HDMI
HDMI to HDMI Video Scaler
1080p
Component Video Scaler
1080p
Composite Video Scaler
1080p
Pure Cinema I/P Converter
Advanced Video Adjustment
Standard Definition Sources Detail, Sharpness, Brightness, Contrast, Hue, Chroma, YNR, Black Level
3D Noise Reduction
Connectivity
HDMI Input / Output
5 In (Rear 5, Assignable 1) / 1 Out
Bluetooth Adapter Port
Optional AS-BT200 or AS-BT100
Component Video Input / Output
2 In (Assignable)
Composite A/V Input / Output
5 In (Front 1, Rear 4) / 1 out
iPod/ iPhone / iPad
Yes (USB+V)
Front USB Memory Input
2 (Front 1, Rear 1 for Wireless LAN)
Ethernet Input
Wireless LAN USB Input
Optional AS-WL300
SIRIUS Satellite Ready
Analog Audio Inputs / Output
3 In / 1 Out
Digital Inputs / Output
4 In
Pre-Amp Output
0.1 Ch (SW)
Headphone Output
Front A/V Inputs
USB / AV Inputs
Power Save for HDMI Stand-by Through
AM/FM Presets
63 Preset AM / FM Tunner
Installation
AVNavigator
On-Screen Display
GUI
iPod / iPhone / iPad Cable
Included
FL Demo Mode (Feature Flashing)
Auto Power Down
Multi-Room and Source Output
2 Zone A/V
IR Serial Remote In/Out
1 In / 1 Out
Multi-Zone On-Screen Display
Zone 2 Text
FL Dimmer
Function Rename
Remote
Learning Remote Control
Sleep Timer
30, 60, 90 min.
Advanced MCACC USB Output
Speaker Configuration
Surround Back/ Front Height/ Front Wide/ Front Bi-Amp/ Zone 2/ B-Speaker
