PANEL

Screen Size

37"

Aspect Ratio

16:9

Native Resolution

1366 x 768p

Pixels (H x V x 3)

3,147,264

Brightness

600 cd/m2

Contrast Ratio

1000:1

Viewing Angle (H x V)

178° x 178°

Color Depth

16.7 Million

Response Time

12 ms

Surface Treatment

Hard Coating (3H)
Anti-Glare

MTBF

50,000 Hr.

VIDEO

Max Input Resolution
(Analog/Digital)

1280 x 1024 @ 60 Hz

Recommended Resolution
(Analog/Digital)

1280 x 1024 @ 60 Hz

H-Scanning Frequency
(Analog/Digital)

30~66 kHz

V-Scanning Frequency

56-85 Hz

Pixel Frequency

165 MHz (D-Sub)
135 MHz (DVI-D)

Sync Compatiblity

Separate/Composite/
SOG/Digital

Video Input

RGB Analog/Digital

EZ Video

Dynamic, Standard,
Mild, Game, User

ACC

Warm, Normal, Cool

REAR INPUTS

Component Video

1 + 1 Hi-Res

PC Input via 15-Pin Sub "D"

1

Composite Video Input/Output

Yes

Audio Inputs

3 Plus PC Sound

HDTV Formats

720p, 1080i

PC Formats

Auto Scaling to XGA

DVI-D

Yes

RS-232C Input/Output

Yes

S-Video

1

Audio Jack Built-in (No Amp)

Yes

Discrete IR Input

Yes

AUDIO

SRS WOW

Yes

Auto Volume Limiter

Yes

Audio Power

20 W (10W x 2)

Balance

Yes

EZ Audio

Flat, Music, Movie,
Speech, User

SPECIAL FEATURES

Picture In Picture (PIP)

Yes, PIP/POP/PBP

Image Zoom

Yes

Source Selection

Digital (DVI-D),
Analog (D-Sub),
Composite, S-Video

Brightness/Contrast

Yes

Color

9300K, 6500K,
User Color (R/G/B)

Position

H/V

Tracking

Auto, Clock, Phase

Set-up

Language (English, French,
Spanish, Korean, Italian,
German, Portugese),
Image Size, OSD
Position, Transparency,
Zoom, Information
(Elapsed Time, Mode)
PIP On/Off, PIP Source,
PIP Size, PIP Position

PIP Image

(Contrast, Brightness,
Sharpness, Color, Tint)

Special

Auto Adjust, OSD Lock

Mute

Yes

Sleep Timer

Yes

Auto Power/Source Memory

Yes

CABINET

Color

Silver/Black

Monitor Dimensions (W x H x D)

36.54" x 22.49" x 4.43"

Weight

55.13 Lbs.

Monitor w/Optional ST3700K
Stand Dimensions (W x H x D)

36.54" x 24.45" x 8.96"

Weight

61.95 Lbs.

Optional SP3700K Speaker
Dimensions (W x H x D)

4.95" x 22.49" x 2.89"

Weight Each

2.56 Lbs.

Backlit Logo

Yes

Optional Wall Mount

RW300

POWER

Power Supply

90~264V/AC
(47-63Hz)

Power Type

Built-in Power

Power Switch Type

Tact Switch &
Mechanical Switch

Power Saving

 -Normal

320 W

 -Stand-by/Suspend

5 W

 -DPM Off

5 W

 -Switch Off

1 W

EPA Energy Star

Yes

SERVICE/LIMITED WARRANTY

Warranty (Parts/Labor)

3 Years

STANDARD (CERTIFICATION)

Safety

UL/CSA/CE/CB
scheme/TUV-GS/
SEMKO

EMC

FCC Class "B"/VCCI/
C-tick/GOST
