PANEL

Screen Size

42"

Aspect Ratio

16:9

Native Resolution

1366 x 768p

Pixels (H x V x 3)

3,147,264

Brightness

600 cd/m2

Contrast Ratio

1000:1

Viewing Angle (H x V)

176° x 176°

Color Depth

16.7 Million

Lamp Life

60,000 Hours (typical)

Response Time

12 ms

Surface Treatment

Hard Coating (3H)
Anti-Glare

MTBF

50,000 Hr.

VIDEO

Max Input Resolution

(Analog)    1600 x 1200 @ 60Hz
(Digital)     1280 x 1024 @ 60Hz

Recommended Resolution

(Analog)    1600 x 1200 @ 60Hz
(Digital)     1280 x 1024 @ 60Hz

H-Scanning Frequency

(Analog)    28-92 kHz
(Digital)     28-80 kHz

V-Scanning Frequency

56-85 Hz

Pixel Frequency

165 MHz (D-sub)
135 Mhz (DVI-D)

Sync Compability

Separate/Composite/
SOG/Digital

Video Input

RGB Analog/Digital

REAR INPUTS

Component Video
(480i/p, 720p, 1080i)

1

Component Video (480i/560i)

1

PC Input via 15-Pin Sub "D"

1

Composite Video Input/Output

Yes

Audio Inputs

3 Plus PC Sound

HDTV Formats

720p, 1080i

PC Formats

Auto Scaling to XGA

DVI-D with HDCP

Yes

RS-232C Input/Output

Yes

S-Video

1

AUDIO

SRS WOW

Yes

Auto Volume Limiter

Yes

Audio Power

20W (10W x 2)

SSM

Yes

SPECIAL FEATURES

Advanced Picture in Picture (PIP)

Yes

Display Mode Change (Vertical)

Yes

Image Zoom

Yes

Source Selection

Digital (DVI-D),
Analog (D-Sub),
Composite, S-Video

Brightness/Contrast

Yes

Color

9300K, 6500K,
User Color (R/G/B)

Position

H/V

Tracking

Auto, Clock, Phase

Set-up

Language (English, French, Spanish), Image Size, OSD Position, Transparency, Zoom, Information (Elapsed Time, Mode) PIP On/Off, PIP Source, PIP Size, PIP Position

PIP Image

(Contrast, Brightness, Sharpness, Color, Tint)

Special

Auto Adjust, OSD Lock

Mute

Yes

Sleep Timer

Yes

Auto Power/Source Memory

Yes

CABINET

Color

Black

Monitor Dimensions (W x H x D)

41.61" x 25.71" x 4.41"

Weight

79.2 Lbs.

Monitor w/Optional ST4200K Stand
Dimensions (W x H x D)

41.61" x 27.44" x 11.60"

Weight

82.0 Lbs.

Optional SP4200K Speaker
Dimensions (W x H x D)

3.94" x 25.71" x 3.07"

Weight

6.1 Lbs.

Optional Wall Mount

RW300

POWER

Power Supply

90~264V/AC
(47-63Hz)

Power Type

Built-in Power

Power Switch Type

Tact Switch &
Mechanical Switch

Power Saving

- Normal

320 W

- Stand-by/Suspend

5 W

- DPM Off

5 W

- Switch Off

1 W

SERVICE/LIMITED WARRANTY

Warranty (Parts/Labor)

3 Years

STANDARD (CERTIFICATION)

Safety

UL/CSA/CE/CB scheme/TUV-GS/ SEMKO

EMC

FCC Class "B"/VCCI/C-tick/GOST
