DIMENSIONS

Cabinet (W x H x D)

18.50" x 14.67" x 8.06"

Weight with Stand

14.6 Lbs.

Weight without Stand

10.9 Lbs.

Carton Dimensions (W x H x D)

21.25" x 17.50" x 10.25"

Shipping Weight

18.56 Lbs.

UPC Code

719192167551

POWER

Consumption

45 Watts

Source

100-240 VAC, 50/60 Hz 0.9A

Stand-by

<3 Watts

Frequency H/V

31-61 kHz/56-85 Hz

ACCESSORIES (Supplied)

15-Wire RGB Cable

Yes

Remote Control

Yes

Power Cord

Yes

APPROVALS

UL, C-UL, NOM

UL, C-UL, FCC (B)

JACK PACK

A/V In Jacks

Yes

RGB In (15-Pin D-sub Connector)

Yes

S-Video In

Yes

RS232C (9-Pin Connector)

Yes

Headphone Jack

Yes

IR Input Jack

Yes

CABINET DESCRIPTION

Finish

Silver

VIDEO ENHANCEMENTS

Screen Size

15.1"

Flat

Yes

Display Type

TFT-LCD

Display Resolution (native)

1024 x 768p (XGA)

Color Depth

16.7 Million

Aspect Ratio

4:3

Brightness

430 cd/m2

Contrast Ratio

350:1

Viewing Angle (H x V)

140° x 120°

Comb Filter

4H Digital

Digital Progressive Scan

Yes

Black Level Expansion

Yes

White Level Compression

Yes

Contrast

Yes

Brightness/Sharpness

Yes

Color/Tint

Yes

EZ Video

Clear, Optimum, Soft, User

OUTPUT RESOLUTIONS

NTSC, W-XGA

1024 x 768p

HDTV

1024 x 768p

DISPLAY

Input Signal

NTSC, PC up to XGA, HDTV (720p, 1080i)

DTV Input

480i - 1080i

PC Input

VGA - XGA 60 Hz

Display Modes

NTSC, PC, HDTV

AUDIO ENHANCEMENTS

On-Screen Equalizer

Yes

On-Screen Balance

Yes

Mono/Stereo/MTS/SAP

Yes

Total Audio

6W (3W x 2)

Auto Volume Leveler

Yes

EZ Audio

Flat, Music, Movie, Sports, User

SPECIAL FEATURES

RS232C Interface

Yes

Built-In SMPS

Yes

Tuning System

RF NTSC 3.58

Channel

VHF/UHF/CATV

Trilingual Menus

English/Spanish/French

Auto Programming (EZ Scan)

Yes

Manual Programming

Yes

Parental Control w/V-Chip

Yes

Sleep Timer

Yes

On/Off Timer

Yes

Auto Off

Yes

Clock

Yes

Flashback

Yes

Closed Captioning

Yes

Auto-Power On & Last Source Memory

Yes

Discrete IR Controls

Yes

Discrete Power Off

Yes

VESA Standard Mount Interface

Yes (100 mm)

Key Lock

Yes

SERVICE/LIMITED WARRANTY

Warranty: Parts/Labor

1 Year/1Year
