KEY POINTS - VR104DP2C Marshall TFT-MegaPixelT Budget 10.4-Inch Field Monitor:
Large 10.4-inch screen
800x600 Dots (1.44 million RGB pixels)
Hyper Process for Interlace Images
Match Color Conversion
100% digital processing
5 Year /50,000 backlight life
Wide viewing radius - 130°
600 (cd/m2) luminance
500:1 contrast ratio
Response rates less than 25 ms
4:3 and 16:9 screen aspect ratios
Direct access for all adjustments
Three color tally indicators
On Screen Display (OSD)
Blue Screen for color adjustment
Color Temperature adjustment
Adjustment Settings Memory
Standard Inputs/Outputs:
2 Composite with auto PAL/NTSC recognition
Loop through of all input signals
Durable metal enclosure
Configurable ¼ 20 Mounting
"V" Mount for Battery included
Runs 4 to 6 hours on optional battery
Power Supply Included
Optical grade polycarbonate screen cover
SUMMARY - Marshall vr104dp2c TFT-MegaPixelT Budget 10.4-Inch Field Monitor:
With 20% more display in a smaller package, our full feature V-R104DP-2C is the perfect alternative to 8 and 9-inch CRTs used in broadcast, professional video and multimedia applications. This model includes our Award Wining Digital TFT-MegapixelT system with 1.44 million pixels plus Hyper Process for interlace image motion compensation.
Inputs are provided for 2 Composite sources that are switch selectable. The analog signals are digitized using a 10 bit process and images are scaled to fit on screen in high resolution using our state of the art LSI with 4x4 pixel interpolation and Match Color Conversion to emulate SMPTE-C phosphor of a CRT. Standard features include V-Mount battery adapter, 4 pin XLR power jack, and optical grade polycarbonate screen protection.
DETAILED SPECS - MARSHALL V-R104DP-2C TFT-MEGAPIXELT BUDGET 10.4-INCH FIELD MONITOR:
Display (Viewing Area)
10.4 Inch diagonal (211.2mm w x 158.4mm h)
Resolution (Pixels)
800 Wide x 600 High (1.44 Million RGB Pixels)(262,000 colors)
Dot Pitch
.264mm square pixel
Brightness (in cd/m)
600
Contrast Ratio
500:1
Inputs
2 Composite
Dimensions
10.25"w x 8.5" h x 2.5" d (260.4mm x 215.9mm x 38.1mm)
Approx.
Weight
4 lbs (1.8 kg)
Power
Consumption
App. 50 Watt (5 Amp 12 VDC Class 2 power supply included)
