Marshall VR104DPHDA Lcd Monitor marshall v-r104dp-hda

KEY POINTS - VR104DPHDA Marshall TFT-MegaPixelT 10.4-Inch Field Monitor with Multiformat Inputs:

Large 10.4-inch screen

800x600 Dots (1.44 million RGB pixels)

Hyper Process for Interlace Images

Match Color Conversion

100% digital processing

5 Year /50,000 backlight life

10 bit Analog to Digital conversion

Wide viewing radius - 130°

600 (cd/m2) luminance

500:1 contrast ratio

Response rates less than 25 ms

4:3 and 16:9 screen aspect ratios

Direct access for all adjustments

Three color tally indicators

On Screen Display (OSD)

Blue Screen for color adjustment

Color Temperature adjustment

Adjustment Settings Memory

Standard Inputs/Outputs:

Component analog (YCrCb) (YPrPb)

for virtually all HD and SD formats

Composite Video auto PAL/NTSC recognition

S-Video

DVI Digital and Analog

PC up to XGA (1024 x 768)

Loop through of all video signals

Durable metal enclosure

Configurable ¼ 20 Mounting

"V" Mount for Battery included

Runs 4 to 6 hours on optional battery

Power Supply Included

Optical grade polycarbonate screen cover

SUMMARY - Marshall vr104dphda TFT-MegaPixelT 10.4-Inch Field Monitor with Multiformat Inputs:

With 20% more display in a smaller package our V-R104DP-HDA is the perfect cost effective alternative to 8 and 9-inch CRTs used in broadcast, professional video and multimedia applications. This model includes our Award Wining Digital TFT-MegapixelT system with 1.44 million pixels plus our exclusive
Hyper Process for interlace image motion compensation.

Match Color Conversion

DETAILED SPECS - MARSHALL V-R104DP-HDA TFT-MEGAPIXELT 10.4-INCH FIELD MONITOR WITH MULTIFORMAT INPUTS:

Display (Viewing Area)

10.4 Inch diagonal (211.2mm w x 158.4mm h)

Resolution (Pixels)

800 Wide x 600 High (1.44 Million RGB Pixels)(262,000 colors)

Dot Pitch

.264mm square pixel

Brightness (in cd/m)

600

Contrast Ratio

500:1

Inputs

Composite , S-Video (Y/C), Component, DVI, PC-XGA (1024 x 768)

Dimensions

10.25"w x 8.5" h x 2.5" d (260.4mm x 215.9mm x 38.1mm)

Approx. Weight

4 lbs (1.8 kg)

Power Consumption

App. 50 Watt (5 Amp 12 VDC Class 2 power supply included)
