Marshall VR151DPAFSD Rack Mount Lcd Monitor marshall v-r151d

KEY POINTS - VR151DPAFSD Marshall 15 inch LCD Monitor with SD inputs and Advanced Features:

High Resolution 1024 x 768 RGB Dots with 2.4 million pixels

16.7 million colors

Wide viewing angles - 160-RL , 140 UD provides superior visibility when the viewer is not directly in front of the screen

Bright 500 candelas per square meter (cd/m) luminance produces enhanced image quality in varying light and viewing conditions

450:1 contrast ratio with response rates less than 23 ms results in excellent quality for moving images.

4:3 and 16:9 screen aspect ratios for DTV applications in HD and SD formats

Standard Multi-format inputs:

SDI (ITU-R BT601 format)
Component Analog HD/SD
Composite Video PAL/NTSC
DVI-I (all formats)
SXGA (1280 x 1024) Computer input (HD-15)

Built in Color Bars

6 Frame Marker Overlays with Center Mark

Easy to see three color tally indicators

Adjustment Settings Memory

SUMMARY - Marshall vr151dpafsd 15 inch LCD Monitor with SD inputs and Advanced Features:

Occupying only 6 SRU and weighing just 12 pounds, the V-R151DP-AFSD has a high resolution LCD display with 2.4 million pixels. It includes our Universal Input configuration and does not require any adapter boxes or expensive options. Standard inputs include active loop through on each connection for SDI, Y/C, and composite video with PAL/NTSC automatic recognition. There is also a multi-format connector for HD or SD analog component signals. For computer graphic applications, this unit also has a scalable SXGA input. Additional features include, setup memory, Zoom function, 6 Frame Marker Overlays and direct access for adjustment and selection functions. With an optional VESA adaptor this monitor can be wall or ceiling mounted. Instruction manual and universal power supply are included.

DETAILED SPECS - MARSHALL V-R151DP-AFSD 15 INCH LCD MONITOR WITH SD INPUTS AND ADVANCED FEATURES:

Display (Viewing Area)

15" (11.95" 8.98")

Resolution (Pixels)

1024 H X RGB X 768 V (2.4 million pixels) (16.7 million colors)

Dot Pitch

0.099 x 0.297 mm

Brightness (in cd/m)

500 cd/m

System

NTSC/PAL auto recognition

Screen Formats

640 x 480 - 59.94i, 60i, 29.97P,30P, 59.94P 60P
1280 x 720 - 23.97P, 24P, 25P, 29.97P, 30P, 59.94P, 60P (using HD-15 or DVI connectors)
1920 x 1080 - 23.97P, 24P, 25P, 29.94P, 30P, 50i, 59.94i, 60i (using HD-15 or DVI connectors)

Inputs

HD-15 (VGA, SVGA, XGA, SXGA, RGBHV, YUV, Y-Pr-Pb) 75W
BNC for SDI (PAL/NTSC) 75W
3 BNCs for Y-Pr-Pb / Y-Cr-Cb
DVI connector for DVI-I
BNC for Composite Video (PAL/NTSC) 75W with AGC
4 Pin Mini Din for S-Video (Y/C)

Dimensions

15.25" w x 10.5" h x 1.77" d (387.35mm x 266.7mm x 44.958mm)

Approx. Weight

12 lbs

Power Consumption

12 VDC, 3.0Amps max - UL Class 2
