Mitsubishi x400u xga 3000 Ansi Lumen LCD Video Projector
Product
Description - mitsubishi x400u lcd video projector
Superb resolution, crisp images and vibrant color definition best describe the
amazing performance of our LVP-X400U and LVP-X400BU models. Features
in addition to 3000 ANSI lumen brightness and XGA resolution with SXGA compatibility
include Natural Color Matrix, Color Uniformity Correction, 2-Live Picture-in-Picture,
Digital Keystone Correction and Digital-Expanded Zoom. Multiple data ports sources,
digital interface, USB terminal and a remote controller with a laser pointer are
also included.
Features
of the Mitsubishi X-400U LCD projector:
The 3000 ANSI
lumen performance of the X400U and X400BU models is supported by a polarized
light conversion element, offering the projection of brilliant, crystal-clear
high-definition images under typical indoor lighting in large spaces.
Click for Picture.
Incorporating
the latest data and image processing technologies, projectors with SXGA
resolution (1,280 x 1,024) projection compatibility provide the reproduction
of high-definition images in bright, true-to-life color. Click
for Picture.
Natural Color
Matrix is an original technology developed by Mitsubishi Electric for
use in the lineup of LVP projectors. The special algorithm created gives
the polysilicon panel display technology used in the company's projectors
color spectrums equivalent to that of CRTs. The six basic colorations
(RGB and YMC) can be adjusted separately, enabling vivid reproduction
of even the most subtle colors such as pastels and flesh tones Click
for Picture.
The Color
Uniformity Correction feature is another one of our newly developed original
technologies that has recently been introduced for practical use.
This feature takes a sample of a color square at the center of the screen
and then matches the colors over the entire image with the sampled data
to create uniform hue.
Eliminating the problem of dissimilarity in colors, which is common to
LCD systems, enables Mitsubishi to ensure sharp, vivid colors for true-to-life
image reproduction. Click for
Picture.
2-Live Picture-in-Picture
enables the presentation of images from two separate sources such as DVD
and computer at the same time, effectively doubling visual information
and presentation impact. Using this feature, a smaller image is inlaid
in a corner of the main screen. Either still or moving images, or a combination
of both can be projected simultaneously. Click
for Picture.
Sometimes
it's not possible to set up the projector perpendicular to the screen.
This can cause distortion to the image projected. Digital Keystone Correction
readjusts trapezoidal and jagged screen images that result from oblique
image projection to give an undistorted picture. Click
for Picture.
This feature
allows you to choose a section of the main screen image and magnify it.
As the data of the selected section is magnified via digital signal processing,
details of the enlarged image remain true to the original.
Click for Picture.
Ports are
provided for multiple data sources including computer, video and RS-232C
serial port connections. (picture below)
A digital
interface terminal has been newly added for easy connection of new personal
computers equipped with DVI, giving Mitsubishi projectors full compatibility
with analog signals and digital computers. Signal degradation is minimized,
resulting in exceptional clarity in image reproduction. Click
for Picture.
A universal
serial bus (USB) port is provided for connecting a USB mouse. This feature
adds greater convenience and ease for projector operation.
A laser pointer
is featured in the handheld remote control unit, allowing you to quickly
and easily pinpoint or highlight specific parts of an image on screen.
Click for Picture.
Every LVP
Series projector is equipped with an on-screen operations menu that is
available in multiple languages. Simply choose the one that best fits
your needs. Click for Picture.
Product
Specifications - mitsubishi x400 lcd video projector
Display
technology
1.3"
Polysilicon panel x 3
Output
terminals
RGB
: Mini D-sub 15pin x 1
Audio
: stereo mini jack x 1 (3.5mm)
Resolution
1024
x 768 (Total 2,359,296 pixels), 540 video lines
Communication
terminals
RS-232C
x 1
(Direct command is available DIN 8pin)
Brightness
3000
ANSI lumens
USB
terminal for Mouse x 1
Colors
16,770,000
colors
Wired
remote terminal x 1 (3.5mm stereo mini jack )
NTSC,
NTSC 4.43, PAL (including PAL-M, N), SECAM, PAL-60
Dimensions
(WxHxD)
299
x 133 x 367mm (excluding lens and legs)
DVD,
HDTV (720p/1080i)
Weight
6.7kg
/ 14.7lbs
Input
terminals
RGB1-A
: Mini D-sub 15pin x 1
Power
supply
AC100
~ 240V ±10%, 50/60Hz
RGB1-B
: DVI x 1
* All contents may subjected to change.
Windows® is a registered trademark of Microsoft Corporation.
Macintosh® is a registered trademark of Apple Computer, Inc.
XGA and SXGA are registered trademarks of IBM Corporation.
All other products or brand names are trademarks or registered trademarks
of their respective holders
