NEC LCD3210BKIT 32 inch HDTV LCD Monitor nec lcd3210bkit

Accessories:

AC power cord,user manual, setup sheet, wireless remote control, batteries, 15-pin RGB cable, CD-ROM,
stands

Brightness

500 cd/m2 (typical)

Colors

256 RGB Level, more than 16 million

Contrast Ratio

600:1

Dimensions:

(WxHxD)
Net (with stand)
31.1 x 20.1 x 7.9 in./789 x 510.3 x 200mm

Net (without stand)
31.1 x 18.9 x 5.5 in./789 x 479 x 140mm

Input Signal:

Video: ANALOG RGB Vp-p / 75 Ohms
Sync: Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)

Input:

RGB1: DVI-D x 1
RGB2: Analog D-sub
RGB3: Analog BNC
Internal Speaker: None
External Control: RS232, DDC/CI

Limited Warranty:

3 year parts and labor, including backlight

Operating Humidity:

20-80%

Operating Temperature:

5-40° C/41-104° F

Pixel Pitch

0.511

Power Consumption:

(typical)
On: 140W
Power Savings Mode: <5W

Regulatory Approvals:

UL 1950/CSA C22.2 No. 950/TUV-GS/EN60950/FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN1000-
3-3/CE

Resolutions Supported:

720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 50-85 Hz
832 x 624 @ 74.5 Hz
1024 x 768 @ 50-85 Hz
1280 x 1024 @ 50-85 Hz
1600 x 1200 @ 60 Hz (Compressed)
1280 x 768 @ 50-85 Hz
1360 x 768 @ 50-85 Hz
NTSC/PAL,SECAM,4.43NTSC,Pal60 HDTV,480i, 480p,720p, 1080i

Storage Humidity:

10-90%

Synchronization Range:

Horizontal: 31.5-91.1 KHz (15.625,15.734 kHz) (Analog)
31.5-91.1 KHz (Digital)
Vertical: 58-85 Hz Analog / 50-85 Hz Digital

Viewing Angle:

176° Vert., 176° Hor. (88U/88D/88L/88R)@ CR>10

Voltage Rating:

AC 100-120V / AC 220-240V @ 50/60 Hz

Weight:

(with stand) 37.5 lbs./17 kg
(without stand) 35.3 lbs./16 kg

Additional Features:

Power Management, Plug and Play (DDC/CI, DDC2B),
PIP (Remote), Multi-level Zoom, FullScan, TileMatrix, TileComp, Screen Saver, Rapid Response, Video Ready (no tuner), Infrared remote control included, removable stand included

Output:

RGB: Daisychain RGB3
Control: RS232 for multiple monitor control

NEC LCD3210BKIT 32 inch HDTV LCD Information Display
