Key Points |
WXGA
resolution (1365x768)
Long life > 60,000 hours
Comprehensive input panel
Enhanced split screen |
|
Unique
Features |
Low Power
Consumption
Highest number of built-in screensavers
AMX Cafe Duet |
|
Plasma
Module |
|
|
Screen Size
(Diagonal) |
50" |
|
Screen
Aspect Ratio 16 to 9 |
16 to 9 |
|
Active
Screen Area (WxH) |
43.5 x 24.4
in, 1104 x 621 mm |
|
Native
Resolution |
WXGA 1365 x
768 |
|
Pixel Pitch |
.81 mm
square |
|
Color
Processing |
1.07
billion colors, 1024 levels |
|
Viewing
Angle |
160 degrees |
|
Half life |
- |
|
Filter Type |
Anti-reflective |
|
Signal
Compatibility/Connectivity |
|
|
Scan Rate |
|
|
Horizontal |
15.5 to
110.0 kHz auto, step scan |
|
Vertical |
51 to120 Hz
auto, step scan |
|
Supported
Video Standards |
PAL, SECAM,
3.58/4.43 NTSC, ATSC |
|
SD/HD Video
Signal Compatibility |
480i, 480p,
525i, 525p, 540p, 625i, 625p, 720p, 1035i, 1080i, 1080p |
|
PC Signal
Compatibility |
VGA, SVGA,
XGA, SXGA, UXGA, WideVGA (848x480, 852x480), WideXGA (1360x768) |
|
Macintosh
Compatibility |
Yes |
|
Input/Output Terminals |
|
|
RGB 1
(analog) |
15-pin mini
D-sub (common use with RGB out, selectable) |
|
RGB 2
(analog) |
5 BNC (RGB/HV)
(common use with 5BNC Y/Pb/Pr input, selectable) |
|
RGB 3
(digital) |
24-pin DVI-D
HDCP (EIA/CEA-861-A) compatible |
|
Video 1 |
Composite
BNC x 1 (common use with Video out, selectable) |
|
Video 2 |
Composite
RCA x 2 |
|
Video 3 |
S-Video
4-Pin DIN |
|
HD Video 1 |
1 set RCA
Component (Y,Pb,Pr/Y,Cb,Cr) |
|
HD Video 2 |
1 set BNC
Component (Y,Pb,Pr/Y,Cb,Cr) (common use with 5BNC Y/Pb/Pr |
|
HD Video 3 |
|
|
HD Video 4 |
|
|
Audio |
3 sets RCA
stereo + external speaker jacks |
|
Audio |
Internal
amplifier, 9W x 2 output power |
|
External
Control |
RS232, IR (IR
loop-through) |
|
RGB
Loop-out |
Yes |
|
Video
Loop-out |
Yes |
|
Electrical |
|
|
Power
Requirements |
120-240V
50/60 Hz |
|
Power
Consumption |
340W
Typical |
|
Standby
Power |
1.0W |
|
Mechanical |
|
|
Dimensions
(WxHxD) |
48.1 x 29.0
x 3.9 in, 1222 x 736 x 99mm |
|
Net Weight |
91.5 lbs.,
41.5 kg |
|
Regulations |
FCC Class
B, UL60950, CSA-E 60950, Argentine UL, NOM |
|
Fan Noise |
22dB |
|
Environmental |
|
|
Operating
Temperature |
32 - 104
degrees F (0 - 40 degrees C) |
|
Operating
Humidity |
20 - 80% |
|
Operating
Altitude |
0 - 6160
feet (0 - 1880m) |
|
Storage
Temperature |
14 - 122
degrees F (-10 - 50 degrees C) |
|
Storage
Humidity |
10 - 90% |
|
Storage
Altitude |
0 to 9510
feet (0 - 2900m) |
|
Warranty |
1 Years
Parts & Labor/1 year plasma module |
|
Additional
Features |
|
|
Split
Screen / Picture-in-Picture |
Yes |
|
Advanced
AccuBlend |
Ensures
detailed images when non-native resolution sources are connected
to the projector. |
|
Phospher
Protection |
7 modes - A
comprehensive set of built-in modes protects your screen from
image retention. |
|
Mass Area
Superior Sampling (MASS) |
- |
|
Enhanced
Mass Area Superior Sampling |
Eliminates
jagged lines, removes color separation and smoothes diagonal
lines for crystal clear and defines sharp images |
|
Capsulated
Color Filter (CCF) technology |
- |
|
AccuCrimson
Filter technology |
- |
|
Advanced
AccuCrimson Filter technology |
Produces
vivid accurate colors by eliminating unwanted internal neon
light emission |
|
Color Tune
Technology |
Adjust
individual colors without affecting white balance. |
|
Gamma 12 |
- |
|
Closed
captioning |
Yes |
|
Matrix
Capability |
2X2, 3X3,
4X4, 5x5, 1X5, 5X1 |
|
In the Box |
AC Power
Cord, User Manual, Remote Control, Batteries, Cable Clamps |
|
Bonded
Color Filter |
Technology
that improves color, bright room contrast and sharpness while
reducing the multiple image reflections possible with
traditional filter technologies. |
