PC/Video:
15 pin D-sub input (RGBHV/YPbPr
input)
15 pin D-Sub connector to take a SCART RGB signal (sync on the
composite line), via an adaptor. Video:
One mini DIN for S-video connector
One composite RCA type connector
USB Mouse control
One Audio input for every input- (3.5mm Mini Jacks stereo)
Output Connections:
15pin monitor output (passive)
Computer Compatibility:
IBM PC and compatibles, Apple Macintosh, iMac, NEC PC98 series,
Fujitsu FM Towns, and VESA standards SXGA, XGA, SVGA, and VGA
(resizing)
Video Compatibility:
NTSC: M(3.58MHz),4.43MHz,480i
PAL: B, D, G, H, I, M, N
SECAM: B, D, G, K, K1, L
HDTV: 480p, 576p, 720p, 1080i
Throw Ratio:
1.75 - 2.12:1distance/width
Keystone Correction:
± 16 degrees
Remote Control:
Wireless remote with optional mouse control
Projection Screen Size (diagonal):
32.5 to 337.5 inches
(0.84 to 8.58 meter)
Projection Distance:
4.6 feet to 39.4 feet (1.4 to 12 meter)
Projection Lens:
F/2.4-2.7; f 19.7 -23.6: 1.2x manual zoom lens
Projection Methods:
Front, rear, ceiling, rear ceiling
Data Loop Through:
Passive monitor loop through
Horizontal Scan Rate:
31.5 to 80 kHz
Vertical Scan Rate:
43 to 85 Hz
Operating Temperature:
41-95°F (5-35°C)
Power Supply:
Universal AC90-264V / 50-60Hz with PFC input
Power Consumption:
280 watts maximum
Security:
One Kensington key lock port
Tilt Angle:
7 degrees with elevator mechanism
IR Receivers:
Front and back
Uniformity:
85%
Displayable Colors:
16.7 million colors, 256 shades of gray
Standard Accessories:
AC power cord (three prong) 1.8m
Composite video cable 1.8m
15pin monitor cable 1.8m
Remote control
Battery for remote
Lens cap (hanging)
Users guide
Quick start guide
Warranty card
SCART to 15 pin D-sub adapter (EMEA only)
Carry case
Optional Accessories:
15-pin to 3 RCA component/HDTV hookup
S-video cable 1.8m
Warranty:
Two year limited parts and labor, 90-days on lamps
