KEY POINTS - Panasonic ptst10u lcd xga short throw portable video projector with 2500 ansi lumens:
Short throw for close range projection
Projects large 80-inch images with a throw distance of only 82 cm
Reduces shadows on-screen
Daylight View technology
XGA native
Up to 500:1 contrast ratio
4:3 aspect ratio
Intelligent power management
Eco friendly with low standby power consumption (0.4 W)
Anti-theft features: security anchor, control panel lock, user password and text superimposing
Wired LAN terminal
Multi projector monitoring and control software
Top panel lamp replacement and side filter replacement for easy maintenance
Speed start (see images on-screen within a few seconds of startup)
Direct power off
Easy setup
Customizable startup logo
Quiet operation (29dB in eco mode)
Up to 5,000 hour lamp life (in eco mode)
Ceiling mountable
Easy-to-use remote control
Variable audio out
Built in speaker
3 year limited warranty
SUMMARY - Panasonic ptst10u LCD XGA Short Throw Portable Video Projector with 2500 ANSI Lumens:
The Panasonic PT-ST10U can project an impressive 80–inch diagonal image from just 2.7-feet away from the screen, allowing users to create big pictures in tight spaces such as small classrooms, conference rooms and trade show booths.
Enhancing its go-to educational application, the PT-ST10U is ideal for use with Interactive White Boards, and offers a White Board Mode that automatically adjusts brightness to suit the white board surface. The short throw projector can be matched with Panasonic's latest elite Panaboard, the UB-T880 Interactive Whiteboard, for enhanced classroom solutions. The UB-T880 has a collapsible projector mount, enabling the whiteboard to be easily moved from room to room without detaching the projector.
The Panasonic PTST10U offers 1024 x 768 XGA resolution and produces 2,800 lumens of brightness. The compact projector weighs approx. 6 1/2 pounds. The PT-ST10 incorporates Panasonic's Intelligent Power Management, new circuitry that ensures continuous supply of power for stable operation even if electricity fluctuates for a short duration. Exclusive Daylight View™ Basic technology measures surrounding illumination with a built-in ambient light sensor, and corrects the image in real-time to project clear, crisp images even in brightly-lit rooms, producing lifelike images with remarkable depth.
For added flexibility, a wired LAN connection enables remote operation, which is especially ideal for ceiling-mounted use. Multi Projector Monitoring and Control Software is available for monitoring and controlling multiple Panasonic projector from a single PC, which means a projector's status and condition can be checked without anyone having to physically walk to the room where it is installed.
The ecological design of the PT-ST10U greatly reduces any environmental impact, with power consumption a mere 0.4W in Eco Standby Mode. Direct Power Off utilizes accumulated power to keep the cooling fan operating until the lamp is cooled, so the operator can disconnect the power cable immediately after use.
Ease of operation and installation are facilitated by several advanced functions, including: Speed Start, slashing the time it takes to begin a presentation, with an image appearing about five seconds after the power button is pressed; One-Touch Auto Setup, automatically correcting the image position when the projector's input signal changes; a built-in gravity sensor correcting automatically for keystone distortion; and a Logo Transfer application enabling a user to customize a start-up logo.
DETAILED SPECS - PANASONIC PT-ST10U LCD XGA SHORT THROW PORTABLE VIDEO PROJECTOR WITH 2500 ANSI LUMENS:
LCD Panel
- Panel size
16 mm (0.63") diagonal, (4:3 aspect ratio)
- Display method
Transparent LCD panel (x3, R/G/B)
- Drive method
Active matrix
- Pixels
1,024 x 768 (x 3) = 786,432 pixels, total pixels: 2,359,296
Optical system
Dichroic mirror separation/prism synthesis system
Lens
Manual zoom (1:1-1:1.2), manual focus, F1.80, f6.74 mm
Lamp
220 W UHM™ lamp
Projection size (diagonal)
1,524-2,794 mm (4:3 aspect ratio)
Colours
Full colour (16,777,216 colours)
Brightness*1
2,800 lumens
Center-to-corner uniformity ratio*1
85%
Contrast ratio*1
500:1 (full on/full off)
Resolution RGB
1,024 x 768 pixels (Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.)
Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
Audio IN
M3 (L, R) x 2, 0.5 V [rms]
Audio OUT
M3 (L, R) x 1, 0-2.0 V [rms] (variable)
Serial
D-sub 9-pin x 1, for external control (RS-232C compliant)
LAN
RJ-45 x 1 for network connection, compliant with PJLink™, 100Base-TX/10Base-T
Remote control
Power supply
3V DC (R03/AAA battery x 2)
Operation range
Approx. 7 m when operated from directly in front of the signal receptor
Dimensions (W x Hx D)
46 x 115 x 21 mm
Weight
64 g (including batteries)
General
Power supply
100-240 V AC, 50/60 Hz
Power consumption
300 W (Approx. 0.4 W with standby mode set to ECO*2; 15 W with standby mode set to NORMAL and 18 W in normal standby mode when set to audio monitor out and with fan stopped.)
