Anti-Clipping Circuit For High Level Undistorted Bass!
Auto On/Off circuit with LED indicator
Gold plated binding posts for a high quality and secure connection
Includes High Quality Gold Plated Interconnect Cable
Internally Braced
Line Level Inputs
Phase Switch
Satellite Speaker Crossover: First Order @ 80 Hz
Solid Brass Isolation Cones
Speaker Level Inputs & Outputs
Stylish Rounded Edge Cabinet Design
Variable Crossover 50-150 Hz
Volume Control
Designed and Assembled in the USA
2 Year Transferable Warranty On Amplifier
7 Year Transferable Warranty On Parts & Labor For The Rest Of The System
SUMMARY - Pinnacle ultrasonic 12 inch Dual 800-Watt Bipole Subwoofer:
The UltraSonic is Pinnacle’s new top of the line powered subwoofer. This state of the art 800 Watt amplifier drives dual 12” woofers in a bipolar configuration. With a maximum output level of 116.5 dB (louder then a jackhammer!), the UltraSonic will fill an oversized room with oversized bass! But the UltraSonic is not just loud, it is also accurate and deep, very deep, down to 20 Hz. It is finished in our beautiful Black Diamond piano finish with elegantly curved sidewalls for a sophisticated, sleek look. Don’t sacrifice beauty and style for massive sound – get both with Pinnacle!
DETAILED SPECS - PINNACLE
ULTRASONIC SUBWOOFER:
System Type: Bipole, Acoustic Suspension
Component Drivers: (2) 12" heavyweight polypropylene cone
woofers with butyl surrounds, 2.5" voice coils, and 50 ounce
magnets
Subwoofer Low End Frequency Response: 20 Hz
Maximum SPL: 116.5 dB
Variable Subwoofer Low Pass Filter: 50 - 150 Hz
System Power: 400 Watts RMS, 800 Watts Peak
Dimensions: 15 3/4" Wide x 22 7/16" High x 16 1/16" Deep (with
Amp & Grilles)
