The Notevision® XR-32X offers brilliant high-resolution images - with 2500 ANSI Lumens brightness, 2200:1 contrast ratio and XGA native resolution. Its HDCP compliant DVI-D input ensures virtually noise-free images from digital sources, while the DLP® display technology delivers superior color quality, brightness and reliability. Ultra-quiet cooling fans along with DLP® sealed system and filter-less lamp design make the projector an ideal choice for extended-use operation.
Closed caption and a full complement of inputs and outputs (including RGB-loop through, stereo variable audio line-output and RS-232C), means the compact and lightweight (6.4 lb.) projector is ideal for both "portable" use and fixed installations.
| Brightness |
2500 ANSI Lumens |
| Display Resolution (Native) |
XGA (1024 x 768) |
| Resolution Capability (Maximum) |
UXGA (1600 x 1200) with ImageACE™ Resizing |
| Compatibility |
Video Compatibility (DTV/HDTV): 480i, 480p, 540p, 576i, 576p, 720p, 1035i, 1080i, 1080p with 4:3 and 16:9 aspect ratios |
| Frequency Range |
15-110 kHz Horizontal / 45-85 Hz Vertical |
| Weight / Dimensions (w x h x d) |
6.4 lbs. / 10.6" x 3.5" x 10.4" (main body) |
| Unique Feature(s) |
Closed Caption (CC1, CC2); Filter-Less Design; Sealed DLP® system; HDCP compliant DVI-D input; Direct Power-Off and Auto-Restart functions; Front Exhaust (to direct cooling air towards "front" of room and away from audience); High-Speed 3x Color Wheel; Interactive Guide; Theft Deterrent Functions; Presentation Assist Remote Control. |
| Panel Type |
0.55" DLP® - 12º |
| Dot Clock |
12-170 MHz |
| PC Compatibility |
Yes |
| Mac® Compatibility |
Yes |
| Video System |
NTSC 3.58, 4.43 / PAL, 60, M, N / SECAM |
| DTV/HDTV Compatibility |
480i, 480p, 540p, 576i, 576p, 720p, 1035i, 1080i, 1080p |
| Video Circuitry |
sRGB plus Brightness Boost and I/P Conversion |
| Resizing |
Intelligent ImageACE™ Resizing for compatibility up through UXGA (1600 x 1200) |
| Contrast Ratio |
2000:1 (with advanced condenser lens optical system) |
| Lens Type |
1:1.15x Short Throw Manual Zoom and Focus, F2.5-2.6, f=20.4-23.5mm, Throw Ratio: 1.8-2.1 |
| PC Control |
RS-232C |
| Remote Control |
IR Wireless Remote Control with forward/back PC presentation and mouse control, on-screen G.U.I. (graphic user interface) pointer and spotlight function, image "freeze" and break timer. |
| Wired Remote |
No |
| Audio System |
2 Watt monaural |
| Lamp |
200 Watt (end-user replaceable) - model number AN-F212LP or AN-F212LP/1 |
| Fan Noise |
32dB in standard mode; 29dB in low-power ("eco + quiet") mode |
| Power Source |
100-240V AC, 50/60Hz (Multi-Voltage) |
| Power Consumption |
267W in "bright" lamp setting / 5W standby |
| Presentation Tools |
Incorporated into the wireless remote: forward/back presentation and mouse control, on-screen G.U.I. (graphic user interface) pointer, spotlight function, image freeze and break timer |
| Limited Warranty |
1 year parts and labor excluding projector lamp. 90 days on user-replaceable projector lamp. |
| Computer Inputs |
DVI-D Digital/RGB/HDCP; Computer/RGB (or Component) – mini D-sub 15 Pin |
| Video Inputs |
DVI-D Digital/RGB/HDCP; Component Video (or RGB/Computer) – mini D-sub 15 Pin; Independent S-Video - 4-pin mini DIN and Composite Video - RCA pin-type |
| Audio Inputs |
PC/Component Stereo Audio Input - 3.5mm stereo mini Connector; "Video" Stereo Audio Input - 1-pair RCA pin-type |
| Outputs |
RGB Monitor Loop-Through - 15 Pin HD; “VAO” (Variable Audio Output) line-out – 3.5mm stereo mini connector |
| Additional Connectors |
RS-232C Input - 9 pin mini DIN |
| Included Accessories |
Wireless Remote Control; two "AA" batteries; 6' AC Power Cord; 10' RGB signal cable; attached lens cap; operation manual; CD-ROM manual |
| Optional Accessories |
AN-XRCM30 ceiling mounting bracket; AN-EP10B extension tube for ceiling mount; AN-JT200 angle mount joint for ceiling mount; AN-CMCSS46 46" security cable system for use with ceiling mount and extension tube; AN-CMCSS16 16" security cable system for use with ceiling mount; AN-C3CP2 component video (3-RCA) to 15-pin D-Sub cable (10'); AN-A1RS RS-232C adaptor; AN-MR2 remote IR receiver (for forward/back presentation control in ceiling mount applications); AN-C500SB lightweight storage bag; AN-C600WCC hard-shell wheeled storage bag; AN-C600SC "ATA" type storage case. Replacement Lamp Module: AN-F212LP or AN-F212LP/1 |
| Min/Max Screen Size |
40" - 300" (diagonal, 4:3) |
| Min/Max Projection Distance |
4' 11" (for 40" diagonal, 4:3) up to 36' 10" (for 300" diagonal, 4:3) |
| Other |
Closed caption; HDCP Compliant DVI-D input; front exhaust system with filter-less design; direct power off and auto re-start; DTV/HDTV compatibility (both 4:3 and 16:9) for use with current and future video technologies Please see spec sheet for additional feature and specification information. |
