Panel

Type

a-si TFT/PVA

Size

19"

Pixel Pitch (mm)

0.294

Brightness

260 cd/m²

Contrast Ratio

700:1

Viewing Angle (H/V)

170/170

Response Time (ms)

25

Aspect Ratio

4:3

Interface

Analog/Digital

Frequency

Horiz. Rate (kHz)

31-81 (Analog)
30-63 (Digital)

Vert. Rate (Hz)

56-75

Bandwidth (Mhz)

135

Resolution

Maximum

1280x1024

Native

1280x1024

Colors

Supported

16.7 Million

Signal Input

Input Video Signal

Analog RGB, DVI Digital Link, CVBS, S-Video, Component, TV (antenna/cable)

Video Level

Analog : 0.7VP-P; Digital: TMDS

Sync Type

Separate H/V, Composite H/V

Input Connectors

15pin D-Sub, DVI-D, S-Video, Component, TV (antenna/cable)

Plug and Play

DDC

1/2B

Power

On/Working (Watts)

62

Wall Mount

VESA

100mm (optional)

Regulations

Safety

UL 1950, CSA, TUV, NEMKO, EK, CCIB, PSB, GOST, SIQ, PCBC, NOM, IRAM, SASO

EMI

FCC, CE, MPR II, VCCI, MIC, BSMI, C-TICK, TUV GS

Emission Standard

TCO '99

Cabinet Color

Front/Back

Silver

Available Colors

Silver

Dimensions (W*H*D)

Physical (inches)

17.0 x 17.2 x 7.8

Packaging (inches)

20.9 x 21.8 x 6.5

Weight

Net (physical)

13.0 lbs

Gross (packaging)

19.6

Features

Special

Built-in TV tuner, dual CPU inputs, S-Video, HDTV ready, PIP function, MagicBright

Included

Warranty

Parts/Labor/Backlight (yrs)

3/3/3
