PANEL

Type

a-si TFT/PVA

Size

19"

Pixel Pitch (mm)

0.294

Brightness (cd/m²)

250 cd/m²

Contrast Ratio

750:1

Viewing Angle

170 / 170

Aspect Ratio

4:3

Response Time

25

Interface

Analog/Digital

FREQUENCY

Horiz. Rate (Analog)

30-81

Horiz. Rate (Digital)

30-63

Vertical Rate

58-75

Bandwidth

140 MHz

RESOLUTION

Maximum (Analog)

1280 x 1024

Maximum (Digital)

1280 x 1024

Native

1280 x 1024

COLOR

Maximum

16.7 M

SIGNAL INPUT

Input Video Signal

Analog RGB, DVI Digital link

Video Level: Analog

0.7VP-P

Video Level: Digital

TMDS

Sync Type

Separate H/V, Composite H/V

Input Connectors

15pin D-sub, DVI-D

PLUG & PLAY

DDC

DDC 2B

POWER

On/Working

45 Watts (Max)

WALL MOUNT

VESA®

75mm

REGULATIONS

Safety

UL 1950, CE, CSA, TUV, IEC 950, NEMKO

EMI/Emissions

FCC, DOC, CISPR22, EMI, EN500821, VCCI

Emission Standard

TCO '99

CABINET COLOR

Front/Back

Silver

DIMENSIONS

Physical (WxHxD)

17.0" x 17.6" x 8.7"

Packaging (WxHxD)

20.6" x 17.8" x 5.8"

WEIGHT

Net(Physical)

12.1 lbs.

Gross (packaging)

17.2 lbs.

FEATURES

Dual interface, Dual hinge slim design, MagicBright, Built-in speaker.

INCLUDED

VESA wall mount (75mm)

OPTIONAL

n/a

WARRANTY

Parts/Labor/Backlight

3 / 3 / 3

COMPATIBILITY

Operating Systems

Windows
Macintosh
Sun Microsystems
