Panel

Type

a-si TFT/TN

Size

17"

Pixel Pitch (mm)

0.264

Brightness

300 cd/m²

Contrast Ratio

600:1

Viewing Angle (H/V)

160/140

Response Time (ms)

25

Aspect Ratio

4:3

Interface

Analog

Frequency

Horiz. Rate (kHz)

31-81

Vert. Rate (Hz)

56-75

Bandwidth (Mhz)

135

Resolution

Maximum

1280x1024

Native

1280x1024

Colors

Supported

16.2 Million

Signal Input

Input Video Signal

Analog RGB, CVBS, S-Video, TV (antenna/cable)

Video Level

Analog : 0.7VP-P

Sync Type

Separate H/V, Composite H/V

Input Connectors

15pin D-Sub, S-Video, RCA Connector, TV (antenna/cable)

Plug and Play

DDC

1/2B

Power

On/Working (Watts)

43

Wall Mount

VESA

75mm (optional)

Regulations

Emission Standard

TCO '99

Cabinet Color

Front/Back

Silver

Available Colors

Silver

Dimensions (W*H*D)

Physical (inches)

15.3 x 15.8 x 8.1

Packaging (inches)

19.0 x 21.3 x 5.8

Weight

Net (physical)

11.8 lbs

Gross (packaging)

15.3

Features

Special

NTSC, S-Video, Built-in tuner, Built-in power, MagicBright

Included

Warranty

Parts/Labor/Backlight (yrs)

3/3/3
