KEY POINTS - Sharp Lc26d7u 26 inch Hdtv
Lcd Tv Monitor
Next-Generation 16:9 LCD Panels
from Sharp’s state-of-the-art Kameyama
factory.
26" Widescreen Advanced Super View LCD Panel
is a Sharp proprietary panel with black TFT
low reflection coating.
Wide XGA (1366 x 768) Resolution
displays HDTV program images in 720p2
and produces a "true" 16:9 aspect ratio.
Digital Cable Ready with CableCARD Slot
enables easy connection to HDTV channels on
compatible cable TV systems without the need
for a separate set-top box.
High Brightness (450 cd/m2)
AQUOS Liquid Crystal Televisions are very
bright. You can put them anywhere -- even
near windows, doors or other light sources
-- and the picture will still be vivid.
High Contrast Ratio (800:1)
provides incredible images whether you're
watching dark or bright scenes.
Wide Viewing Angles (170º H / 170º V)
Sharp's viewing angles are so wide, you can
view the TV clearly from anywhere in the
room!
Detachable Speakers/Included Table Stand
are the ultimate in convenience!
Quick Shoot
Sharp’s proprietary fast response time video
circuit.
SUMMARY - Sharp Aquos LC26D7U 26
inch HDTV Ready Widescreen LCD TV Monitor
Sharp’s
LC-26D7U AQUOS is an elegant statement for
any room in the home. With a true 16:9
aspect ratio, HDTV resolution of 1366 x 768
and breathtaking color purity, it is a
next-generation TV to carry you into the
high-definition future. The LC-26D7U
utilizes Sharp’s Emmy Award-winning LCD
technology, including the proprietary
Advanced Super View/Black TFT Panel, which
provides high brightness (450 cd/m2),
an 800:1 contrast ratio, and wide viewing
angles (170º x 170º).
The LC-26D7U is
Digital Cable Ready with full CableCARD
"Plug and Play" capability. It also features
the new TV Guide On Screen electronic
program guide for easy channel management
and selection, and an elegant new titanium
finish with detachable speakers. In
addition, the included table stand can be
easily removed for wall mounting
applications. Other features that
distinguish the LC-26D7U: HDMI, DVI-I and 2
HD component video inputs, and Sharp’s
proprietary Quick Shoot video circuit, which
enables a fast response time 16 ms or below.
DETAILED SPECS -
SHARP LC26D7U HDTV LCD TV DISPLAY
Panel Type
26" Active Matrix (a-si TFT) Advanced
Super View LCD
Pixel Resolution
Wide XGA (1366 x 768)
Video System
NTSC
Brightness
450 cd/m2
Lamp Life
60,000 hours
Viewing Angles
170º H / 170º V
Audio System
10W + 10W
Tuner Type
Frequency Synthesizer (Analog/Digital)
Limited Warranty
1 year parts and labor
Contrast Ratio
800:1
Aspect Ratio
16:9
Color Temperature
Selectable: 13000ºK, 9500ºK, 8000ºK,
6500ºK, 5000ºK
(values are approximate)
View Modes
Sidebar, Smart Stretch, Stretch, Zoom,
Dot by Dot (for PC), Normal (for PC)
DVI Input
DVI-I x 1
RS-232C Input
9-pin mini D-sub x 1
HDMI Input
HDMI x 1
HD Component Input
Y/Pr/Pb x 2
S-Video Input
4-pin DIN x 1
Composite Video Input (A/V)
RCA x 3
Table Stand
Included
Backlight
Fluorescent Lamp (Cold Cathode Type)
S-Video Output
4-pin DIN x 1
Audio Inputs
RCA L/R x 3
Audio Outputs
Optical Digital Audio Output x 1, RCA
L/R x 1, 3.5mm Stereo Minijack x 1
Dimensions
(w x h x d)
26 17/32" x 22 21/64" x 10 35/64"
(with table stand and with speakers)
26 17/32 x 22 21/64" x 10 35/64"
(with table stand and without speakers)
26 17/32" x 20 5/16" x 4 31/64"
(without table stand and with speakers)
26 17/32" x 16 29/64" x 4 1/4"
(without table stand and without
speakers)
Weight
37.9 lbs. (with table stand and with
speakers)
33.5 lbs. (with table stand and without
speakers)
29.4 lbs. (without table stand and with
speakers)
25.0 lbs. (without stand and without
speakers)
