Display Resolution XGA (1024 x 768)

Resolution Capability UXGA (1600 x 1200)

Compatibility VGA through UXGA (1600 x 1200)

Frequency Range fH, 15-126 kHz/fV 43-200 Hz

Weight / Dimensions 11.7 lbs. 9" x 4.75 x 12.2"

Unique Feature(s) 1700 ANSI Lumens with 90% CCR, Compact yet bright

Price (MSRP) $5,195

Panel Type 3 - 0.9" Polysilicon TFT LCD

Dot Clock 230 MHz

PC Compatibility XGA (VGA to UXGA w/ ImageACE)

Mac Compatibility 1024 x 768(up to 1280 x 1024 w/Image ACE)

WS Compatibility 1024 x 768(various modes w/ImageACE

Video System NTSC/PAL/SECAM

HD Compatibility 480I/480P/720P/1080I - 4.3 and 16.9 Aspect Ratios

Video Circuitry 3D Y/C Circuitry, interlaced/progressive scan

Resizing Advanced ImageACE Resizing - up to UXGA

Center to Corner Ratio 0.9

Lens Type 1.1.3x Manual Zoom and Focus

PC Control RS-232C

Remote Control IR w/Mouse Control, Laser Pointer

IR Carrier Frequency 40kHz

Wired Remote 3.5 mm minijack

Audio System 2 Watt Monaural

Lamp 200 Watt, UHP User-replaceable

Fan Noise 37 dB

Power Source 110-240V AC, 50/60Hz

Power Consumption 310 Watts

Presentation Tools "PresenterPAK"

Warranty 3 Years Parts/Labor and Sharp ER, Lamp 90 Days

Computer Inputs 2 - RGB/Computer Inputs (15 pin HD Female)

Video Inputs (1) RCA or S-Video

Outputs 1 RGB 15 Pin

Min/Max Screen Size 40" to 300" (Diagonal)

Min/Max Projection Distance 4.63' to 46.03'
