LCD Panel

Type

13" color TFT active matrix XGA LCD

Display Area

10.4" horizontal x 7.9" vertical; 13" diagonal

Optimum Resolution

640x480

Contrast Ratio

500:1 (typical)

Viewing Angle

130° horizontal, 110° vertical

Response Time

22ms (Tr=6ms, Tf=16ms)

Brightness

450 nits (typical)

Aspect Ratio

4:3

Glass Surface

Anti-glare

INPUT SIGNAL

Video

Composite, Component (YCbCR), S-video, RF (antenna/cable)

AUDIO OUTPUT

Speakers

2x2.5 watts

CONNECTOR

Signal Input

Composite, component YCbCr, S-video, RCA audio, AV/SV RCA audio (L/R), antenna coaxial

Signal Output

Mini stereo, RCA audio (L/R)

Power

3 pin plug

POWER

Voltage

AC 90-240V (universal), 47-63Hz

Consumption

60W (max)

CONTROLS

Basic

Power, enter, menu, channel +/-, volume +/-

OSD

Picture (contrast, brightness, color, tint, sharpness), audio (balance, bass, treble, audio out), option menu (caption, input, memory recall), set-up menu (TV/CATV, autoscan, channel, parental control)

OPERATING CONDITIONS

Temperature

41°-95°F (5-35°C)

Humidity

10-90% (non-condensing)

DIMENSIONS
(WxHxD)

Physical

16.8" x 13.6" x 7.6"
426mm x 346mm x 195mm

WEIGHT

Net

8.8 lb. (4.04 kg)

Gross

12.9 lb. (5.9 kg)

REGULATIONS

UL, cUL, FCC class B, ENERGY STAR

WARRANTY

One-year limited warranty on parts, labor and backlight.
