LCD Panel

Type

18" color TFT active matrix XGA LCD

Display Area

14.5" horizontal x 11.0" vertical; 18.1" diagonal

Optimum Resolution

1024x768

Contrast Ratio

350:1 (typical)

Viewing Angle

160° horizontal, 110° vertical

Response Time

35ms (typical)

Brightness

400 cd/m2 (typical)

Panel Surface

Anti-glare

VIDEO INPUT

Analog

RGB analog (75 ohms, 0.7/1.0 Vp-p) TV/cable, S-video, composite (RCA), component YPbPr 3.5 mm mini stereo audio in/out and RCA (left/right) audio in

Frequency

fh:30~60kHz, fv:50~75Hz

Sync

H/V Separated (TTL)

COMPATIBILITY

PC

Compatible from VGA up to 1024 x 768

Mac

Power Mac G3/G4 up to 1024 X 768
(*Adapter may be required. Analog adapter available from ViewSonic)

CONNECTOR

Analog

15-pin mini D-sub

Power

3-pin plug

POWER

Voltage

AC 100–240V (universal) 50-60Hz

Consumption

60W (typical)

CONTROLS

Basic

Power enter, channel +/- and volume +/-

OnView

(PC mode) Auto adjust, contrast/brightness, color adjust, information, image adjust (H/V position, H. size, fine tune), source select (PC, YPbPr, S-video, AV, TV/CATV), setup (OSD position, time out) and memory recall

(Video mode) Contrast, brightness, color, tint (except YPbPr), sharpness, sound (balance, bass, treble), source select (PC, YPbPr, S-video, AV, TV/CATV) PIP (source select, YPbPr, S-video, AV or TV/CATV, AV position, on/off) and memory recall

(TV mode) Contrast, brightness, color, tint, sharpness, sound (balance, bass, treble, mute), closed caption (OFF, C1,C2, C3,C4, T1, T2,T3, T4) source select (PC, YPbPr, S-video, AV, TV/CATV) setup (TV/CATV select, autoscan, channel add/delete, parental control) and memory recall

OPERATING CONDITIONS

Temperature

32–104°F (0–40°C)

Humidity

10–90% (non-condensing)

DIMENSIONS
(WxHxD)

Physical

540mm (W) x 411mm (H) x 238mm (D)
21.3" x 16.2" x 9.4"

WEIGHT

Net

14.1lbs (6.4kgs)

Gross

20.5lbs (9.3kgs)

REGULATIONS

UL, cUL, FCC class B, ICES003, MPR II

WARRANTY

One-year limited warranty on parts, labor and backlight
