LCD Panel

Type

20" color TFT active matrix XGA LCD

Display Area

16.1" horizontal x 12.0" vertical; 20.1" diagonal

Optimum Resolution

640x480

Contrast Ratio

500:1 (typ)

Viewing Angle

160° horizontal, 140° vertical

Response Time

16ms (Tr=5ms, Tf=11ms)

Brightness

450 nits (typ)

Aspect Ratio

4:3

Glass Surface

Anti-glare

INPUT SIGNAL

Video

Composite, component (YPbPr), S-video, RF (antenna/cable)

AUDIO OUTPUT

Speakers

2x5-watt

CONNECTOR

Signal Input

Composite, component YCbCr, S-video, RCA audio, AV/SV RCA audio (L/R), antenna coaxial

Signal Output

Mini stereo, RCA audio (L/R)

Power

3 pin plug

POWER

Voltage

AC 90240V (universal), 4763Hz

Consumption

75W (max)

CONTROLS

Basic

Power, enter, menu, channel +/-, volume +/-

OSD

Picture (contrast, brightness, color, tint, sharpness), audio (balance, bass, treble, audio out), option menu (caption, input, memory recall), set-up menu (TV/CATV, autoscan, channel, parental control)

Remote Control

Included

OPERATING CONDITIONS

Temperature

32°-104°F (040°C)

Humidity

10-65% (non-condensing)

DIMENSIONS
(WxHxD)

Physical

23.9" x 17.4" x 9.8"
608mm x 443mm x 250mm

WEIGHT

Net

22.0 lb. (10.0 kg)

Gross

27.3 lb. (12.4 kg)

REGULATIONS

cUL, FCC class B, ENERGY STAR, ICS003, BSMI

WARRANTY

One-year limited warranty on parts, labor and backlight

PRODUCT DIMENSIONS W/STAND

23.9"x 17.4"x 9.8"

PRODUCT DIMENSIONS W/OUT STAND

23.9x 3"x 14.5"

SUGGESTED CONSTRUCTION PLANNING DIMENSIONS W/STAND*

25.9"x10.8"x 19.4"

SUGGESTED CONSTRUCTION PLANNING DIMENSIONS W/WALL MOUNT

25.9"x 8.5"x19.4"
