LCD

Type

0.99" Poly-Si TFT with micro-lens

Pixel Format

1024x768 XGA (native resolution)

Lens

Power zoom/focus

Zoom Factor

1.5

Keystone

Vertical ± 15° horizontal ± 5°

DISPLAY

Size

40-500" (Diagonal)

Throw Distance

47" - 913"

Lamp

275W, 4000 hours

Brightness

3,500 lumens

Contrast Ratio

800:1

Aspect Ratio

4:3, 16:9

AUDIO

Speakers

2x1 watts

INPUT SIGNAL

Video

RGB analog, NTSCM, NTSC 4.45, PAL, SECAM, HDTV (480i, 480p, 575i, 720p, 1080i)

Sync

Separated

Frequency

Fh: 15-91KHz; Fv:50-120Hz

COMPATIBILITY

PC

Analog: from VGA up to UXGA (compressed)

Mac++

Analog: up to SXGA

CONNECTOR

PC Input

Analog RGB: DB-15 (x1), Digital RGB: M1-D, BNCx5 connector (x1 set)

RGB Output

DB-15

Composite Video Input

RCA jack (x1)

Component Video Input

RCA jack (x1 set)

S-Video Input

Mini-DIN 4-pin (x1)

Audio Input

3.5mm stereo mini jack (x2) for RGB, RCA L/R jack (x1 set) for video

Audio Output

3.5mm stereo mini jack (x1)

Control

RS-232 USB for mouse control (through M1)

Network

RJ-45

POWER

Voltage

90-264VAC, 50-60Hz (universal)

Consumption

430 watts (typical)

USER CONTROLS

Physical

Standby, menu, input, reset, H/V keystone, search, focus, zoom, volume

OnView

Language, display (brightness, contrast, aspect, picture position, gamma, mirror, language, color bar (R, B) sharpness, color, tint, V/H position, H phase, H size, over scan, auto adjust, video, HDTV, sync on green, blank, start up, myscreen, myscreen size, myscreen lock, whisper, auto off, audio (volume, mute), projection (front, rear, front ceiling, rear ceiling), lamp (lamp timer, lamp timer reset), filter (filter timer, filter timer reset), service, network

OPERATING CONDITIONS

Temperature

32-95°F (0-35°C)

Humidity

10-85% (non-condensing)

NOISE LEVEL

Normal

40dB (typical)

Whisper mode

36dB (typical)

DIMENSIONS
(WXDXH)

Physical

420mm x 160mm x 320mm
(16.5" x 6.3" x 12.6")

WEIGHT

Net

17.0 lb. (7.7 kg)

Gross

26.5 lb. (12.0 kg)

REGULATIONS

UL60950/C-UL , FCC B, TUV/GS, CB, CE, C-Tick, GOST, NOM, CCC, PSB

OTHER

Progressive scan, digital gamma correction, over scan, picture-in-picture, remote with mouse control, monitor pass through, auto adjust

WARRANTY

Three-year limited warranty on parts and labor, first-year Express Exchange Service. One-year warranty on lamp.
