Projector Accessories

2 Year Warranty Extension

DLP

Type

0.7" XGA DLP

Pixel Format

1024 Horizontal x 768 Vertical (XGA)

Lens

Manual focus, manual zoon

DISPLAY

Size

27.6" to 267.2" (measured diagonally)

Throw Distance

47" - 394" (1200mm - 6620mm)

Lamp

120W, 2,000 hour rating

Brightness

1,100 Lumens

Contrast Ratio

2000:1

Aspect Ratio

4:3, 16:9

INPUT SIGNAL

Video

RGB analog, NTSC M, NTSC 4.43, PAL (B, D, G, H, I, M, N), SECAM (B, D, G, K, K1, L), 480i/p, HDTV 720p, 1080i

Sync

Separated

Frequency

Fh : 15-100kHz; Fv : 43-120Hz

COMPATIBILITY

PC

Analog: from VGA to SXGA (scaled)

Mac++

Analog: to SXGA (may require Mac Adapter)

CONNECTOR

RGB

DB-15

Composite Video

RCA

Component Video

VGA to component adapter

S-Video

Mini DIN 4-Pin

POWER

Voltage

100-240 VAC/50-60Hz (universal)

Consumption

170W (typical)

USER CONTROLS

Remote

Power, source, PIP, Keystone, zoom, hide, freeze, menu

OnView

Brightness, contrast, aspect ratio, menu location language, sharpness, color temp, tint, V/H position, PIP, zoom, keystone correction

OPERATING CONDITIONS

Temperature

41° - 95° F (5°- 35° C)

Humidity

10% to 85% (non-condensing)

NOISE LEVEL

Normal

36dB dB (typical)

DIMENSIONS
(WXDXH)

Physical

198mm x 57mm x 148mm
(7.8" x 2.2" x 5.8")

WEIGHT

Net

.95 kg (2.1 lb.)

REGULATIONS

UL, C-UL, FCC-Class B, CB, CE, TUV/GS, NOM, PSB/S-mark, C-Tick, CCC, VCCI, GOST

OTHER

Front and rear projection, zoom feature, PIP, wireless remote control, soft carrying case.

WARRANTY

Three-year limited warranty on parts and labor, first-year Express Exchange Service. One-year warranty on lamp.
