LCD

Type

0.7" P-Si TFT

Pixel Format

800x600 SVGA

Lens

Zoom lens/manual focus

Zoom Factor

1.2

DISPLAY

Size

30"-300" (measured diagonally)

Throw Distance

35"-433"

Throw Ratio

1:49~1.79:1

Lamp

165W, 4000 hour rating

Brightness

1,600 lumens

Contrast Ratio

400:1

Aspect Ratio

4:3 (native),16:9

Digital Keystone Correction

±15º vertical

AUDIO

Speakers

1x1-watt

INPUT SIGNAL

Computer

RGB anaolg

Video

NTSC, NTSC 4:3, PAL, SECAM, 480i/p, HD signals 720p, 1080i

Frequency

Fh:15-91kHz; Fv:50-120Hz

COMPATIBILITY

PC

Analog: VGA to UXGA (scaled)

Mac++

Analog: up to SXGA

CONNECTOR

RGB

15-pin HD, D-sub cable

Video Input

S-video, composite, component

Audio Input

RCA (x1)

Control

RS-232

POWER

Voltage

100-240 VAC, 50-60Hz (universal)

Consumption

220 watts (typical)

USER CONTROLS

Physical

Standby on/off, menu, input

Remote

Standby on/off, page up, page down, enter, volume, mute, blank, auto adjust, search, RGB, video, aspect, magnify on/off, freeze, position, keystone, reset, escape

OnView

Language [English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Chinese, Korean, Swedish, Russian, Polish], Display [keystone, brightness, contrast, aspect, whisper, mirror, language, gamma, color], Balance (RGB) [sharpness, color, tint, my memory, H/V position, H phase, H size, overscan, color space, component, video, frame lock, 3D-YCS, video NR, progressive, information, S2-aspect, adjust, power-off, search, blank, start up, menu position, message, screen type, reset], Audio [volume, mute], Lamp [timer, timer reset], Filter [timer, timer reset]

OPERATING CONDITIONS

Temperature

32°-95°F (0°-30°C)

Humidity

10-85% (non-condensing)

NOISE LEVEL

Normal

33dB (typical)

Whisper mode

29dB (typical)

DIMENSIONS
(WXDXH)

Physical

11.7" x 9.2" x 2.5"
297mm x 234mm x 64mm

WEIGHT

Net

5.4 lb. (2.4 kg)

Gross

14.3 lb. (6.5 kg)

REGULATIONS

UL, C-UL, FCC-Class B, CB, CE, TUV/GS, C-Tick, NOM

OTHER

Front and rear projection, overscan, frame lock, 3D-YCS, video NR, progressive scan, soft carrying case, remote control

WARRANTY

Three year limited warranty on parts and labor, first-year Express Exchange Service. One-year limited warranty on lamp.
