Xenarc 570M-3 5.7-Inch TFT LCD Monitor with AV Input

No Longer Available

Back to Xenarc LCD Main

Click For Larger Image

Like our 5" models, this monitor provides a high resolution display in a smaller size, but if you're looking for a larger screen, check out the specifications on this 5.7" monitor.  It includes a hassle free vertical auto screen reverse function, allowing the monitor to switch the image on the screen vertically by itself depending on whether the monitor is installed right side up or right side down.

Its multi-functionality also includes a horizontal mirror image function, for images such as rear-view which need to be mirror-imaged.

These monitors come included with the stand mount shown to the right, Audio/Video cables, and an AC adapter.

To install this monitor in a vehicle, check out the BSM-1 Headrest Mount

• Color / Brightness / Volume Adjustable
• AV Input x 1
• NTSC / Pal Multi-System Auto Switch
• Vertical Auto Screen Reverse Function
• Horizontal Mirror Image Function
• High Resolution Display - 960 x 234

• Model #: 570M-3
• Screen Size:  Diagonal 5.7"
• Display Resolution:  320 (H) x 234 (V)
• Dot Resolution: 960 x 234 = 224,640 (dots)
• Operating Voltage:  DC 12V ±10%
• Power Supply:  DC 12V, 1A
• Power Consumption:  <7W
• Operating Temperature:  23°F ~ 158°F
• Video Source:  1Vp-p, 75Ω
• Dimension (in):  6.63W x 5.25H x 1.25D
• Weight (lb):  0.84
• FCC, CE
