Key Points |
WXGA resolution (1365x768)
Comprehensive input panel
Enhanced split screen |
|
Unique Features |
Most accurate color reproduction with 68.7 billion colors
Long life > 60,000 hours
Highest number of built-in screensavers |
|
Plasma Module |
|
|
Screen Size (Diagonal) |
50" |
|
Screen Aspect Ratio |
16 to 9 |
|
Active Screen Area (WxH) |
43.5 x 24.5 in, 1106 x 622 mm |
|
Native Resolution |
WXGA 1365 x 768 |
|
Pixel Pitch |
1.08 mm square |
|
Color Processing |
68.7 billion colors, 4096 levels |
|
Viewing Angle |
160º |
|
Half life |
60,000 hours |
|
Filter Type |
Anti-reflective |
|
Signal Compatibility/Connectivity |
|
|
Scan Rate |
|
|
Horizontal |
15.5 to 110.0 kHz auto, step scan |
|
Vertical |
51 to120 Hz auto, step scan |
|
Supported Video Standards |
PAL, SECAM, 3.58/4.43 NTSC, ATSC |
|
SD/HD Video Signal Compatibility |
480i, 480p, 525i, 525p, 540p, 625i, 625p, 720p, 1035i,
1080i,1080p |
|
PC Signal Compatibility |
VGA, SVGA, XGA, SXGA, UXGA, WideVGA (848x480, 852x480),
WideXGA (1360x768) |
|
Macintosh Compatibility |
Yes |
|
Input/Output Terminals
(Click For Larger Image) |
 |
|
RGB 1 (analog) |
15-pin mini D-sub (common use with RGB out, selectable) |
|
RGB 2 (analog) |
5 BNC (RGB/HV) (common use with 5BNC Y/Pb/Pr input,
selectable) |
|
RGB 3 (digital) |
24-pin DVI-D HDCP (EIA/CEA-861-A) compatible |
|
Video 1 |
Composite BNC x 1 (common use with Video out, selectable) |
|
Video 2 |
Composite RCA x 2 |
|
Video 3 |
S-Video 4-Pin DIN |
|
HD Video 1 |
1 set RCA Component (Y,Pb,Pr/Y,Cb,Cr) |
|
HD Video 2 |
1 set BNC Component (Y,Pb,Pr/Y,Cb,Cr) (common use with 5BNC Y/Pb/Pr |
|
Audio |
3 sets RCA stereo + external speaker jacks |
|
Audio |
Internal amplifier, 9W x 2 output power |
|
External Control |
RS232, IR(IR loopthrough) |
|
RGB Loop-out |
Yes |
|
Video Loop-out |
Yes |
|
Electrical |
|
|
Power Requirements |
120-240V 50/60 Hz |
|
Power Consumption |
435W Typical |
|
Standby Power |
0.9W |
|
Technical |
|
|
Dimensions (WxHxD) |
48.1 x 29.0 x 3.8 in, 1222 x 736 x 96mm |
|
Net Weight |
97.9 lbs., 44.5 kg |
|
Regulations |
FCC Class B, UL60950, CSA-E 60950, Argentine UL, NOM |
|
Fan Noise |
20dB |
|
Environmental |
|
|
|
Operating Temperature |
32 - 104 degrees F (0 - 40 degrees C) |
|
Operating Humidity |
20 - 80% |
|
Operating Altitude |
0 - 9180 feet (0 - 2800m) |
|
Storage Temperature |
14 - 122 degrees F (-10 - 50 degrees C) |
|
Storage Humidity |
10 - 90% |
|
Storage Altitude |
0 to 9840 feet (0 - 3000m) |
|
Warranty |
1 Years Parts & Labor/1 year plasma module |
|
Additional Features |
|
|
Split Screen / Picture-in-Picture |
Yes |
|
Advanced AccuBlend |
Ensures detailed images when non-native resolution sources are
connected to the projector. |
|
Phosphor Protection |
6 modes - A comprehensive set of built-in modes protects your
screen from image retention. |
|
Mass Area Superior Sampling (MASS) |
No |
|
Enhanced Mass Area Superior Sampling |
Eliminates jagged lines, removes color separation and smoothes
diagonal lines for crystal clear and defines sharp images |
|
Capsulated Color Filter (CCF) technology |
CCF delivers realistic color reproduction creating the
greatest color space when plotted on the C.I.E. Chromaticity
chart. |
|
AccuCrimson Filter technology |
Further enhances the effects of the CCF producing better reds
and greens. |
|
Advanced AccuCrimson Filter technology |
No |
|
Color Tune Technology |
Adjust individual colors without affecting white balance. |
|
Gamma 12 |
Provides the highest color processing in a plasma display at
68.7 billion colors (4096 steps) resulting in increased detail
never seen before... no matter what the viewing environment! |
|
Closed captioning |
Yes |
|
Matrix Capability |
2X2, 3X3, 4X4, 5x5 |
|
In the Box |
AC Power Cord, User Manual, Remote Control, Batteries, Cable
Clamps |
