Size

42"

Dimensions

40.43x24.82x3.11 inches (WxHxD)

Weight

68.3lbs (31 Kg)

Aspect Ratio

16:9

Resolution

1024x768

Pixel Pitch (mm)

0.912x0.693 mm

Brightness (cd/m²)

1000

Contrast Ratio

3000:1

Colors

16.7 Million (256 RGB levels)

INPUT TERMINALS

Composite Video

1xRCA

S-Video

1xDin-4pin

Component 1

3xRCA (Y/Pb/Pr)

Component 2

3xBNC (Y/Pb/Pr)

RGB 1 (PC 1)

1xD-sub 15pin

RGB 2 (PC 2)

5 x BNC (RGB HV)

DVI

1x29pin DVI

RS-232C

1x mini jack

Audio

1xmini jack, 2 sets RCA

OUTPUT TERMINALS

Composite Video ~ 1 x RCA
Speaker - External Speaker Jack
Audio - 2xRCA (L/R)
RS232C - 1x D-sub 9-pin

SPECIAL FEATURES

Multi-Layer Anti-Reflection Filter
Built-in Protection (Auto Pixel Shift, Signal Pattern Processor, All White)
Multi-Region Color System (PAL, SECAM, NTSC 3.58, NTSC 4.43)
4H Digital Comb Filter
Selectable color temperature (normal, cool1, cool2, warm1, warm2)
Selectable picture mode (Video: custom, dynamic, standard, movie. PC: custom, high, middle, low)
Multiple Display Control (RS232C)
Display power management signaling
Digital noise reduction
Progressive scan
Variable aspect ratio (6 modes: wide, panorama, zoom1, zoom2, 14:9, normal)
Picture in picture, picture by picture
Clock phase adjustment
Real time clock, On/Off Timer
Digital zoom, picture freeze
Built-in matrix video wall processor (2x2, 3x3, 4x4, 1x5, 5x1)
Vertical pivot display DNIe picture compensation algorithm


Scan System

Progressive Scan

Color System

Multi (PAL/SECAM/NTSC3.58/NTSC4.43)

Digital Comb Filter

4H Comb Filter

Color Temperature

Normal/Cool1/Cool2/Warm1/Warm2

Picture Mode

Custom, Dynamics, Standard, Movie (PC: Custom, high, middle, low)

Screen Mode

Wide, zoom1, zoom2, 14:9, normal

WARRANTY

2 yr parts and labor, on-site service

SAFETY REGULATIONS

CE, UL1492, UL6500, CSA C22.2, FCC Class B

OPERATING CONDITIONS

Temperature

0~50 degrees C

Humidity

20~80%

Altitude

700 ~ 1,114 hps

INCLUDED

Table-top stand, remote control (batteries included), power cord, speaker wires, MDC S/W, Pivot S/W, PC Cable, MDC Cable, Owner's Instructions
